Especificaciones Técnicas
| Código del Producto | Modelo | Rango de temperatura(℃) | Temperatura Fluctuante (℃) | Resolución de temperatura (℃) | Capacidad(L) | Flujo de la bomba de circulación(L/min) | Apertura de la ranura de trabajo(mm) | Fuente de alimentación |
|---|---|---|---|---|---|---|---|---|
| B-01-01-02-020101 | BellBaCirTemConsBajT-05 | 0~100 | 0.01 | ±0.05 | 8 | 6 | 320x370x670 | 220V±10%, 50/60Hz |
| B-01-01-02-020102 | BellBaCirTemConsBajT-08 | 0~100 | 0.01 | ±0.05 | 8 | 16 | 320x370x670 | 220V±10%, 50/60Hz |
| B-01-01-02-020103 | BellBaCirTemConsBajT-0508 | -5~100 | 0.01 | ±0.05 | 8 | 16 | 320x370x670 | 220V±10%, 50/60Hz |
| B-01-01-02-020104 | BellBaCirTemConsBajT-1008 | -10~100 | 0.01 | ±0.05 | 8 | 16 | 320x370x670 | 220V±10%, 50/60Hz |
| B-01-01-02-020105 | BellBaCirTemConsBajT-1508 | -15~100 | 0.01 | ±0.05 | 8 | 16 | 320x370x670 | 220V±10%, 50/60Hz |
| B-01-01-02-020106 | BellBaCirTemConsBajT-2008 | -20~100 | 0.01 | ±0.05 | 8 | 16 | 320x370x670 | 220V±10%, 50/60Hz |
| B-01-01-02-020107 | BellBaCirTemConsBajT-3008 | -30~100 | 0.01 | ±0.1 | 8 | 16 | 320x370x670 | 220V±10%, 50/60Hz |
| B-01-01-02-020108 | BellBaCirTemConsBajT-4008 | -40~100 | 0.01 | ±0.1 | 8 | 16 | 400x450x850 | 220V±10%, 50/60Hz |
| B-01-01-02-020109 | BellBaCirTemConsBajT-010 | 0~100 | 0.01 | ±0.05 | 10 | 18 | 320x370x770 | 220V±10%, 50/60Hz |
| B-01-01-02-020110 | BellBaCirTemConsBajT-0510 | -5~100 | 0.01 | ±0.05 | 10 | 18 | 320x370x770 | 220V±10%, 50/60Hz |
| B-01-01-02-020111 | BellBaCirTemConsBajT-1010 | -10~100 | 0.01 | ±0.05 | 10 | 18 | 320x370x770 | 220V±10%, 50/60Hz |
| B-01-01-02-020112 | BellBaCirTemConsBajT-2010 | -20~100 | 0.01 | ±0.05 | 10 | 18 | 320x370x770 | 220V±10%, 50/60Hz |
| B-01-01-02-020113 | BellBaCirTemConsBajT-3010 | -30~100 | 0.01 | ±0.1 | 10 | 18 | 320x370x770 | 220V±10%, 50/60Hz |
| B-01-01-02-020114 | BellBaCirTemConsBajT-015 | 0~100 | 0.01 | ±0.05 | 15 | 16 | 320x370x770 | 220V±10%, 50/60Hz |
| B-01-01-02-020115 | BellBaCirTemConsBajT-0515 | -5~100 | 0.01 | ±0.05 | 15 | 16 | 320x370x770 | 220V±10%, 50/60Hz |
| B-01-01-02-020116 | BellBaCirTemConsBajT-1015 | -10~100 | 0.01 | ±0.05 | 15 | 16 | 320x370x770 | 220V±10%, 50/60Hz |
| B-01-01-02-020117 | BellBaCirTemConsBajT-2015 | -20~100 | 0.01 | ±0.05 | 15 | 16 | 400x450x850 | 220V±10%, 50/60Hz |
| B-01-01-02-020118 | BellBaCirTemConsBajT-3015 | -30~100 | 0.1 | ±0.1 | 15 | 16 | 400x450x850 | 220V±10%, 50/60Hz |
| B-01-01-02-020119 | BellBaCirTemConsBajT-4015 | -40~100 | 0.1 | ±0.1 | 15 | 16 | 400x450x980 | 220V±10%, 50/60Hz |
| B-01-01-02-020120 | BellBaCirTemConsBajT-020 | 0~100 | 0.01 | ±0.05 | 20 | 16 | 400x450x980 | 220V±10%, 50/60Hz |
| B-01-01-02-020121 | BellBaCirTemConsBajT-0520 | -5~100 | 0.01 | ±0.05 | 20 | 16 | 400x450x980 | 220V±10%, 50/60Hz |
| B-01-01-02-020122 | BellBaCirTemConsBajT-1020 | -10~100 | 0.01 | ±0.05 | 20 | 16 | 400x450x980 | 220V±10%, 50/60Hz |
| B-01-01-02-020123 | BellBaCirTemConsBajT-2020 | -20~100 | 0.01 | ±0.05 | 20 | 16 | 400x450x1080 | 220V±10%, 50/60Hz |
| B-01-01-02-020124 | BellBaCirTemConsBajT-030 | 0~100 | 0.01 | ±0.05 | 30 | 16 | 400x550x1000 | 220V±10%, 50/60Hz |
| B-01-01-02-020125 | BellBaCirTemConsBajT-0530 | -5~100 | 0.01 | ±0.05 | 30 | 16 | 400x550x1000 | 220V±10%, 50/60Hz |
| B-01-01-02-020126 | BellBaCirTemConsBajT-1030 | -10~100 | 0.01 | ±0.05 | 30 | 16 | 400x550x1000 | 220V±10%, 50/60Hz |
| B-01-01-02-020127 | BellBaCirTemConsBajT-2030 | -20~100 | 0.01 | ±0.05 | 30 | 16 | 400x550x1000 | 220V±10%, 50/60Hz |
| B-01-01-02-020128 | BellBaCirTemConsBajT-040 | 0~100 | 0.01 | ±0.05 | 40 | 16 | 400x550x1100 | 220V±10%, 50/60Hz |
| B-01-01-02-020129 | BellBaCirTemConsBajT-1040 | -10~100 | 0.01 | ±0.05 | 40 | 16 | 400x550x1100 | 220V±10%, 50/60Hz |
| B-01-01-02-020130 | BellBaCirTemConsBajT-150 | 0~100 | 0.01 | ±0.05 | 50 | 16 | 540x650x1150 | 220V±10%, 50/60Hz |
| B-01-01-02-020131 | BellBaCirTemConsBajT-1050 | -10~100 | 0.01 | ±0.05 | 50 | 16 | 540x650x1150 | 220V±10%, 50/60Hz |
