Automatic Mortar Flexural Compression Test Machine

Name: [B-01-200-0107] Automatic Mortar Flexural Compression Test Machine
Brand: Belltronic
SKU: B-01-200-0107

Esta combinación no existe.

SKU: B-01-200-0107

Overview

Automatic Mortar Flexural Compression Test Machine B-01-67-0548 para laboratorio de ingenieria civil.

Contenido estructurado en formato Aurora a partir de tablas tecnicas del proveedor.

Vista

Especificación	0.1 ~ 10 kN / s - ±0.1 % - Compression
Type of Mode	Compression
Max.Capacity	300 kN
Piston Stroke	120 mm
Speed Control Range	0.1 ~ 10 kN / s
Vertical Clearance	180 mm
Fixed Top Compression Platen	Ø108 mm
Fixed Bottom Compression Platen	Ø205 mm
Speed Control Accuracy	±0.1 %
Load Accuracy	±1.0 %
Resolution	0.01 kN
Overall Dimensions	600(W) x 1300 (L) x 1620 (H) mm
Power	240 V; 750 W; 1 ph; 50 / 60 Hz
Approx. Weight	460 kg

Variante	Type of Mode	Max.Capacity	Piston Stroke	Speed Control Range	Vertical Clearance	Fixed Top Compression Platen	Fixed Bottom Compression Platen	Speed Control Accuracy	Load Accuracy	Resolution	Overall Dimensions	Power	Approx. Weight
0.1 ~ 10 kN / s - ±0.1 % - Compression	Compression	300 kN	120 mm	0.1 ~ 10 kN / s	180 mm	Ø108 mm	Ø205 mm	±0.1 %	±1.0 %	0.01 kN	600(W) x 1300 (L) x 1620 (H) mm	240 V; 750 W; 1 ph; 50 / 60 Hz	460 kg
