| Modelo | B-01-200-0490 |
|---|
| Capacidad de carga | 1200 kN |
| Clase de maquina | Clase 1 |
| Exactitud de carga | ±1% |
| Resolucion de desplazamiento | 0.001 mm |
| Carrera del piston | 200 mm |
| Velocidad maxima del cabezal movil | 240 mm/min |
| Velocidad de ensayo | 100 mm/min |
| Tamano de toron de acero | Ø8 - Ø18 mm |
| Tamano de probeta redonda | Ø14 - Ø45 mm |
| Distancia maxima de ensayo de flexion | 300 mm |
| Carga Bastidor :- | Carga Bastidor :- |
| - Max. Bearing Deformacion | ≤ 0.45 mm |
| - Coaxility | < 0.03 mm |
| - Cilindro Layout | Tipo inferior |
| - Max. Bearing Capacidad of Oil Cilindro | 1500 kN |
| - Cilindro Linearity | |
| Ellipticity | ≤ 0.015 mm |
| Verticality | ≤ 0.03 mm |
| Roughness | ≤ Ra 0.4 μm |
| Oil Sources :- | Oil Sources :- |
| - Pump ; | |
| Flujo | 6.26 l/min |
| Presion | 20.4 Mpa |
| - Transducer ; | |
| Sensitivity Coefficient | 2 mv/v |
| Nonlinear | 0.2% FS |
| Repeatability | 0.05% |
| Force rango de medicion | 12 - 1200 kN |
| Relativa error of Ensayo Force Indication | ± 1% |
| Force Resolucion | 1/300000 FS |
| Resolucion de desplazamiento | 1/300000 FS |
| Displacement Indication error | ≤ ± 0.5mm |
| Deformacion Resolucion | 1/300000 FS |
| Deformacion Resolucion error | ≤ ± 0.5% |
| Equal tasa Control Rango of Ensayo Force | 0.1 - 4% FS |
| Displacement Constant tasa Control Rango | 0.5 - 90 mm/min |
| Strain Constant tasa Control Rango | 0.00007 - 0.0025/s |
| Velocidad Control Exactitud error | ≤ ± 1% of Set Value |
| Max. Distance Between Superior & Inferior Presion Plates | 980 |
| Paralleslism of Superior & Inferior Pressing Plates | ≤ 0.01 mm |
| Flatness of Pressing Plate | < 0.016 mm |
| Dureza of Pressing Plate | > 55 HRC |
| Surface Roughness of Pressing Plate | < 0.8 μm |
| Maximum Distance Between Stretching Jaws | 1090 mm |
| Effective Distance Between Columns | 680 mm |
| Clamping Width of Flat probeta | ≤ 100 mm |
| Clamping Thickness of Flat probeta | 0 - 40 mm |
| Clamping Dia. of Round probeta | 15 - 60 mm |
| Dimensiones Of Superior & Inferior Pressing Plates | 240 x 240 mm |
| Dimensiones (Carga Bastidor) | 950 (L) x 700 (W) x 2810 (H) mm |
| Dimensiones de consola de control | 1100 x 750 x 900 mm |
| Alimentacion | 220 V, 1Ph, 50 / 60 Hz |
| Peso de consola de control | 300 kg |
| Peso del bastidor | 4550 kg |
