| Tipo de calentamiento | Air Jacket | Air Jacket | Air Jacket | Air Jacket |
| Rango de temperatura | RT+5-55℃ | RT+5-55℃ | RT+5-55℃ | RT+5-55℃ |
| Resolucion de temperatura | 0.1℃ | 0.1℃ | 0.1℃ | 0.1℃ |
| Fluctuacion de temperatura | ±0.1℃ | ±0.1℃ | ±0.1℃ | ±0.1℃ |
| Uniformidad de temperatura | ±0.3℃ | ±0.3℃ | ±0.3℃ | ±0.3℃ |
| Sensor de CO2 | Infrared Sensor measuring range: 0.0-21.0% | Infrared Sensor measuring range: 0.0-21.0% | Infrared Sensor measuring range: 0.0-21.0% | Infrared Sensor measuring range: 0.0-21.0% |
| Rango de control de CO2 | 0.0-20.0% | 0.0-20.0% | 0.0-20.0% | 0.0-20.0% |
| Precision de control de CO2 | ±0.1% | ±0.1% | ±0.1% | ±0.1% |
| Camara interior | Heating steel | Heating steel | Heating steel | Heating steel |
| Carcasa exterior | Cold-Roll Steel Sheet, Surface electrostatic spraying | Cold-Roll Steel Sheet, Surface electrostatic spraying | Cold-Roll Steel Sheet, Surface electrostatic spraying | Cold-Roll Steel Sheet, Surface electrostatic spraying |
| Capa aislante | Polyurethane | Polyurethane | Polyurethane | Polyurethane |
| Calentador | Heating sheet | Heating sheet | Heating sheet | Heating sheet |
| Metodo de humedad | Disk humidifier | Disk humidifier | Disk humidifier | Disk humidifier |
| Potencia nominal | 0.4kW | 0.5kW | 0.6kW | 0.7kW |
| Ventilacion de gas | 27mm rear (with test hole function) | 27mm rear (with test hole function) | 27mm rear (with test hole function) | 27mm rear (with test hole function) |
| Otro | HEPA filter | HEPA filter | HEPA filter | HEPA filter |
| Modo de control de temperatura | PID control | PID control | PID control | PID control |
| Modo de ajuste de temperatura | 5.0-inch touch screen | 5.0-inch touch screen | 5.0-inch touch screen | 5.0-inch touch screen |
| Modo de visualizacion de temperatura | Temperature displayed on left, concentration displayed on right screen | Temperature displayed on left, concentration displayed on right screen | Temperature displayed on left, concentration displayed on right screen | Temperature displayed on left, concentration displayed on right screen |
| Temporizador | 0-9999 minutes (with timing wait function) | 0-9999 minutes (with timing wait function) | 0-9999 minutes (with timing wait function) | 0-9999 minutes (with timing wait function) |
| Funcion de operacion | Fixed value operation, timed operation, automatic stop | Fixed value operation, timed operation, automatic stop | Fixed value operation, timed operation, automatic stop | Fixed value operation, timed operation, automatic stop |
| Funcion de esterilizacion | UV sterilization, wet heat sterilization, sterilization at high temperature 140/180℃ | UV sterilization, wet heat sterilization, sterilization at high temperature 140/180℃ | UV sterilization, wet heat sterilization, sterilization at high temperature 140/180℃ | UV sterilization, wet heat sterilization, sterilization at high temperature 140/180℃ |
| Funcion adicional | Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power off parameter memory | Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power off parameter memory | Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power off parameter memory | Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power off parameter memory |
| Sensor | PT100, water level sensor, infrared CO2 sensor | PT100, water level sensor, infrared CO2 sensor | PT100, water level sensor, infrared CO2 sensor | PT100, water level sensor, infrared CO2 sensor |
| Dispositivo de seguridad | High temperature alarm, concentration alarm, other alarm | High temperature alarm, concentration alarm, other alarm | High temperature alarm, concentration alarm, other alarm | High temperature alarm, concentration alarm, other alarm |
| Camara interior (An x Pr x Al) | 345*375*388 | 404*439*454 | 509*472*632 | 540*500*670 |
| Tamano exterior (An x Pr x Al) | 500*500*655 | 585*585*766 | 593*746*842 | 629*791*893 |
| Tamano del embalaje (An x Pr x Al) | 620*620*855 | 705*705*966 | 713*866*1042 | 749*911*1093 |
| Volumen | 50L | 80L | 150L | 180L |
| Numero maximo de estantes | 4 | 5 | 6 | 7 |
| Carga por estante | 15kg | 15kg | 15kg | 15kg |
| Espacio de estante | 35mm | 35mm | 35mm | 35mm |
| Alimentacion (50/60HZ) | AC220V/1.8A | AC220V/2.3A | AC220V/2.7A | AC220V/3.2A |
| Peso neto / bruto (kg) | 55/70 | 97/112 | 93/108 | 115/130 |
| Numero de carcasa estandar | 2 | 2 | 2 | 2 |
| Rack shelf estandar | 4 | 4 | 4 | 4 |
| Accesorios opcionales | (Optional 90 ℃ wet heat sterilization carbon dioxide infrared sensor) Shelf, printer | (Optional 90 ℃ wet heat sterilization carbon dioxide infrared sensor) Shelf, printer | (Optional 90 ℃ wet heat sterilization carbon dioxide infrared sensor) Shelf, printer | (Optional 90 ℃ wet heat sterilization carbon dioxide infrared sensor) Shelf, printer |
