| Primary Application | High-resolution measurement of small display & component features | High-resolution measurement of small display & component features |
| Working Distance to Front of Lens | 40 mm | 42 mm |
| Approx. Field of View * (by camera sensor size) | 2MP: 1.7 x 1.3 mm 8MP: 3.6 x 2.7 mm 29MP: 6.5 x 4.3 mm 45MP: 5.4 x 3.6 mm 61MP: 6.5 x 4.3 mm | 2MP: 0.8 x 0.6 mm 8MP: 1.8 x 1.4 mm 29MP: 3.4 x 2.2 mm 45MP: 2.6 x 1.7 mm 61MP: 3.4 x 2.2 mm |
| Spatial Resolution * (by camera sensor size) | Up to 29MP: 1.10 µm / sensor pixel 45MP: 0.64 µm / sensor pixel 61MP: 0.74 µm / sensor pixel | Up to 29MP: 0.55 µm / sensor pixel 45MP: 0.32 µm / sensor pixel 61MP: 0.37 µm / sensor pixel |
| Approx. Effective F-Stop | F/20 | F/40 |
| Measurement Capabilities * | Luminance, Radiance, Luminous Intensity, Radiant Intensity, Power, Radiant Flux, CIE Chromaticity Coordinates, Correlated Color Temperature (CCT) | Luminance, Radiance, Luminous Intensity, Radiant Intensity, Power, Radiant Flux, CIE Chromaticity Coordinates, Correlated Color Temperature (CCT) |
| Units * | foot-lambert, cd/m 2 , nit, W/sr/m 2 , foot-candles, candela, W/sr, CIE (x, y) and (u’, v’), Kelvin (CCT) | foot-lambert, cd/m 2 , nit, W/sr/m 2 , foot-candles, candela, W/sr, CIE (x, y) and (u’, v’), Kelvin (CCT) |
