| Primary Application | Uniformity Testing, R&D Settings, Production Line Testing, Display Testing, Color Correction |
| Sensor Pixel Resolution | 9568 x 6380 |
| Sensor Megapixels | 61.0 |
| Sensor Type | CMOS |
| System Dynamic Range (single exposure, per pixel) | 76 dB (1 x 1 binning) |
| Luminance (Minimum)* | 0.0005 cd/m 2 Limit of Detection 0.0010 cd/m 2 @ SNR = 60 0.0015 cd/m 2 @ SNR = 100 |
| Luminance (Maximum) | 10 10 cd/m 2 with optional ND filters |
| Imaging Colorimeter Accuracy** | Illuminance ± 3%; Luminance (Y) ± 3%; Color Coordinates (x,y) ± 0.003 |
| Short-term Repeatability* | Illuminance ± 0.02%; Luminance (Y) ± 0.02%; Color Coordinates (x,y) ± 0.00005 |
| Lens Type | Electronically controlled focus and aperture |
| Focal Distances Available | 50, 100 mm |
| Field of View (Full Angle, H x V degrees) | 50 mm 40° x 28° 100 mm macro 20° x 14° |
| Minimum Measurement Time*** | 0.6 sec - photopic 1.8 sec - color |
| Spatial Measurement Capabilities | Luminance, Radiance, Illuminance, Irradiance, Luminous Intensity, Radiant Intensity, CIE Chromaticity Coordinates, L*a*b* Color Scale, Correlated Color Temperature (CCT), Dominant Wavelength |
| Units | foot-lambert, cd/m 2 , nit, W/sr/m 2 , foot-candles, lux, lux-s, W/m 2 , W-s/m 2 , candela, W/sr, CIE (x, y) and (u’, v’), Kelvin (CCT) |
| Communication Interface | 10 Gigabit Ethernet (10 GigE) |
| Power | 100-240 V, 50-60 Hz, 140 Watts |
| LCD Touch Panel | Resolution: 800 x 600; Diagonal: 125 mm |
| Dimensions (H x W x D) | 238 mm x 181 mm x 230 mm |
| Peso | 4.6 kg |
| Temperatura de operación | 5 - 35° C |
| Operating Humidity | 20 - 70% non-condensing |
