| Primary Application | Production, Display Testing, Pixel-level Measurement, Advanced Vision | Production, Display Testing, Pixel-level Measurement, Advanced Vision | Production, Display Testing, Pixel-level Measurement, Advanced Vision | Production, Display Testing, Pixel-level Measurement, Advanced Vision | Production, Display Testing, Pixel-level Measurement, Advanced Vision |
| Sensor Pixel Resolution | 5312 x 3032 | 5312 x 3032 | 5312 x 3032 | 8040 x 5360 | 9568 x 6380 |
| Sensor Megapixels | 16.1 | 16.1 | 16.1 | 43.1 | 61.0 |
| Sensor Type | CMOS | CMOS | CMOS | CCD | CMOS |
| System Dynamic Range (single exposure, per pixel) | 70 dB (1 x 1 binning) | 70 dB (1 x 1 binning) | 70 dB (1 x 1 binning) | 59 dB (1 x 1 binning) | 76 dB (1 x 1 binning) |
| Luminance (Minimum) * | 0.0005 cd/m 2 Limit of Detection 0.0010 cd/m 2 @ SNR = 60 0.0015 cd/m 2 @ SNR = 100 | 0.0005 cd/m 2 Limit of Detection 0.0010 cd/m 2 @ SNR = 60 0.0015 cd/m 2 @ SNR = 100 | 0.0005 cd/m 2 Limit of Detection 0.0010 cd/m 2 @ SNR = 60 0.0015 cd/m 2 @ SNR = 100 | 0.0001 cd/m 2 Limit of Detection 0.0001 cd/m 2 @ SNR = 60 0.0005 cd/m 2 @ SNR = 100 | 0.0005 cd/m 2 Limit of Detection 0.0010 cd/m 2 @ SNR = 60 0.0015 cd/m 2 @ SNR = 100 |
| Luminance (Maximum) | 10 10 cd/m 2 with optional ND filters | 10 10 cd/m 2 with optional ND filters | 10 10 cd/m 2 with optional ND filters | 10 10 cd/m 2 with optional ND filters | 10 10 cd/m 2 with optional ND filters |
| System Accuracy ** | Illuminance ± 3%; Luminance (Y) ± 3% | Illuminance ± 3%; Luminance (Y) ± 3% | Illuminance ± 3%; Luminance (Y) ± 3% | Illuminance ± 3%; Luminance (Y) ± 3% | Illuminance ± 3%; Luminance (Y) ± 3% |
| Short-term Repeatability * | Illuminance ± 0.03%; Luminance (Y) ± 0.03% | Illuminance ± 0.03%; Luminance (Y) ± 0.03% | Illuminance ± 0.03%; Luminance (Y) ± 0.03% | Illuminance ± 0.02%; Luminance (Y) ± 0.02% | Illuminance ± 0.02%; Luminance (Y) ± 0.02% |
| Lens Type | Electronically controlled focus and aperture | Electronically controlled focus and aperture | Electronically controlled focus and aperture | Electronically controlled focus and aperture | Electronically controlled focus and aperture |
| Focal Distances Available | 35, 50, 100 mm | 35, 50, 100 mm | 35, 50, 100 mm | 35, 50, 100, 200 mm | 35, 50, 100, 200 mm |
| Field of View (Full Angle, H x V degrees) | 35 mm 24° x 14° 50 mm 17° x 10° 100 mm macro 8° x 5° | 35 mm 24° x 14° 50 mm 17° x 10° 100 mm macro 8° x 5° | 35 mm 24° x 14° 50 mm 17° x 10° 100 mm macro 8° x 5° | 35 mm 55° x 37° 50 mm 40° x 28° 100 mm macro 20° x 14° 200 mm 11° x 7° | 35 mm 55° x 37° 50 mm 40° x 28° 100 mm macro 20° x 14° 200 mm 11° x 7° |
| Minimum Measurement Time *** | 0.5 sec | 0.5 sec | 0.5 sec | 1.4 sec | 0.7 sec |
| Spatial Measurement Capabilities | Luminance, Radiance, Illuminance, Irradiance, Luminous Intensity, Radiant Intensity | Luminance, Radiance, Illuminance, Irradiance, Luminous Intensity, Radiant Intensity | Luminance, Radiance, Illuminance, Irradiance, Luminous Intensity, Radiant Intensity | Luminance, Radiance, Illuminance, Irradiance, Luminous Intensity, Radiant Intensity | Luminance, Radiance, Illuminance, Irradiance, Luminous Intensity, Radiant Intensity |
| Units | foot-lambert, cd/m 2 , nit, W/sr/m 2 , foot-candles, lux, lux-s, W/m 2 , W-s/m 2 , candela, W/sr | foot-lambert, cd/m 2 , nit, W/sr/m 2 , foot-candles, lux, lux-s, W/m 2 , W-s/m 2 , candela, W/sr | foot-lambert, cd/m 2 , nit, W/sr/m 2 , foot-candles, lux, lux-s, W/m 2 , W-s/m 2 , candela, W/sr | foot-lambert, cd/m 2 , nit, W/sr/m 2 , foot-candles, lux, lux-s, W/m 2 , W-s/m 2 , candela, W/sr | foot-lambert, cd/m 2 , nit, W/sr/m 2 , foot-candles, lux, lux-s, W/m 2 , W-s/m 2 , candela, W/sr |
| Communication Interface | Ethernet 1000 | Ethernet 1000 | Ethernet 100/1000, USB 2.0 | 10 Gigabit Ethernet (10 GigE) | 10 Gigabit Ethernet (10 GigE) |
| Power | External AC / DC adapter, 100-240 V, 50-60 Hz, 60 Watts | External AC / DC adapter, 100-240 V, 50-60 Hz, 60 Watts | External AC / DC adapter, 100-240 V, 50-60 Hz, 60 Watts | External AC / DC adapter, 100-240 V, 50-60 Hz, 60 Watts | External AC / DC adapter, 100-240 V, 50-60 Hz, 60 Watts |
| Dimensions (H x W x D) | 86 mm x 86 mm x 170 mm | 86 mm x 86 mm x 170 mm | 86 mm x 86 mm x 154 mm | 86 mm x 86 mm x 154 mm | 86 mm x 86 mm x 170 mm |
| Peso | 1.1 kg | 1.1 kg | 1.4 kg | 1.4 kg | 1.2 kg |
| Temperatura de operación | 5 - 35° C | 5 - 35° C | 5 - 35° C | 0 - 30° C | 5 - 35° C |
| Operating Humidity | 20 - 70% non-condensing | 20 - 70% non-condensing | 20 - 70% non-condensing | 20 - 70% non-condensing | 20 - 70% non-condensing |
