| BE-NPlatC-5b | BE-NPlatC-8b | BE-NPlatC-9b |
| BE-NPlatC-II-5B | BE-NPlatC-II-8B | BE-NPlatC-II-9B |
| Funcion | Max. Temperatura (℃) | SH-5, SH-8, SH-9: 320
SH-5B, SH-8B, SH-9B: 350 ℃
SH-II-5B, SH-II-8B, SH-II-9B: 400 |
| Estructura | Concha exterior | Soldadura de placa de hierro, pulverización de superficie |
| Plato caliente | Tensil de aluminio: SH-5, SH-5B, SH-8, SH-8B, SH-9, SH-9B:
Placa de grafito: SH-II-5B, SH-II-8B, SH-II-9B: |
| Poder de calefacción (W) | SH-5: 800
Sh-5b: 1200
SH-II-5B: 1800 | SH-8: 1500
SH-8B: 2400
SH-II-8B: 3000 | SH-9: 2200
SH-9B: 3500
SH-II-9B: 4500 |
| Controlador | Método de ajuste | Escala: SH-5, SH-8, SH-9
Digital: SH-5B, SH-8B, SH-9B, SH-II-5B, SH-II-8B, SH-II-9B |
| Temporizador | No / digital |
| Sensor de temperatura | Modelo k |
| Temperatura. exactitud | SH-5, SH-8, SH-9: ± 10%
SH-5B, SH-8B, SH-9B, SH-II-5B, SH-II-8B, SH-II-9B: ± 1% |
| Temp. Temp. Uniformidad | SH-5, SH-8, SH-9: ± 15%
SH-5B, SH-8B, SH-9B, SH-II-5B, SH-II-8B, SH-II-9B: ± 10% |
| Especificación | Tamaño exterior (W * L * H) (mm) | 340 * 370 * 220 | 420 * 500 * 220 | 470 * 650 * 220 |
| Tamaño de embalaje (W * L * H) (mm) | SH-5 / SH-5B: 520 * 380 * 250
SH-II-5B: 550 * 410 * 270 | SH-8 / SH-8B: 560 * 520 * 250
SH-II-8B: 600 * 560 * 270 | SH-9 / SH-9B: 660 * 620 * 250
SH-II-9B: 700 * 660 * 270 |
| Tamaño de la placa (mm) | 300 * 300 | 350 * 450 | 400 * 600 |
| Carga de placa | 20kg | 30kg | 40kg |
| Fuente de alimentación (50 / 60Hz) | 220v |
| NW / GW (kg) | SH-5 / SH-5B: 9/10
SH-II-5B: 12 /13.5 | SH-8 / SH-8B: 11/12
SH-II-8B: 19/20 | SH-9 / SH-9B: 15/17
SH-II-9B: 28/30 |
